CLS Double Row Symmetric Cycle Shelters

CENTAUR CLS16 (4 Bay) Double-Row Symmetric Cycle Shelter

The larger version of the CS cycle shelter, CENTAUR CLS provides weather protection for two rows of cycle stands with a 4000mm cover width. With the same aesthetically pleasing design from a symmetric barrel-vaulted roof and central-fixed radius steel support structure.

Often selected for larger schemes to form a cycle shelter compound where the site is secure or within an area of high pedestrian traffic and the overall visual impact of the structure is a consideration.

Get a quote

CENTAUR CLS Product Specification & Options (E Shop)

  • Product Specifications

    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    CLS2020no. Cycles404251503054DownloadDownloadDownload
    CLS24 24no. Cycles404261503054DownloadDownloadDownload

  • Cycle Stand Options

    • Rail Fix (Toast Rack)

      Stands are surface mounted to ground fix steel rails.

    • Baseplate

      Integral base plates for individual ground fixing.

    • Root Fix

      Stands are cast into concrete below ground.

  • Steel Finishes

    urbanspec Bike shelters have a hot dip galvanised frame finish as standard and this is a coating that is highly durable in all environments. An optional powder coated finish can be selected from the following RAL colours together with coordinated cycle stands. Images are for illustrative purposes only.

    • Hot-Dip Galvanised

    • Colour Polyester Powdercoat
