Enclosed Bin Screens

Canopies & Walkways

Enclosed Bin Screens

Covered Bin Screen Iroko cladding
S3 (Bank of 2 Units) Enclosed Bin Screen – ForestPanel Iroko (Horizontal Pattern) – PPC RAL7016 Anthracite Grey Finishes (Frame / Roof)
Covered Bin Screen Iroko cladding
Covered Bin Screen Iroko cladding

urbanspec Enclosed bin screens

urbanspec S-Series Covered Bin Screens are the premium screening solution for waste containers with interlocking cover panels to access bins for loading and removal without the need for hinged doors.

read more...

Designed for high-rise developments where views from upper floors are a particular consideration, unique self-supporting cover sections combine with the base frame and panels to fully enclose the bins. The sliding door sections use a heavy duty roller-track system on the base frame to access the waste containers. Hook-type locking systems secure the sliding door sections, restricting unauthorised access.

S-Series covered bin screens are available in two sizes with capacity for two or three four-wheeled bins of up to 1280L capacity. Cladding systems include sustainably sourced softwood and hardwood with both vertical and horizontal fixing patterns and a variety of coloured steel cladding options.

Inspirational bin screens are made possible with custom hole pattern designs laser cut into coloured steel cladding panels, the addition of vinyl wrap graphics and further options of integral sedum green roof.

show less
Quote MY PROJECT

urbanspec S-Series Covered Bin Screens Specification & Options

  • Product Availability and Dimensions

    urbanspec  S-Series covered bin screens are available in two sizes with capacity for two or three four-wheeled bins of up to 1280L capacity. The space required is kept to a minimum thanks to the unique sliding doors, allowing units to be situated directly adjacent to pathways.
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    S22no. 660L-1280L 4-Wheeled Bins128030801670DownloadDownloadDownload
    S33no. 660L-1280L 4-Wheeled Bins128045701670DownloadDownloadDownload

  • Cladding and Finishes

    urbanspec bin screens are available in a range of cladding options within the standard frame design for selection according to the site use, architectural style and surrounding environment. (specifications subject to change without notice) Images are for illustrative purposes only.

    • Firenze Freestyle Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection 30% Gloss Finish
      • Laser Cut Hole Pattern Design

    • Firenze Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection

    • Firenze Anthracite Grey

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Nordic Night Black

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Leaf Green

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Walnut Brown

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • ForestPanel SW Slat

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative (Green)

    • ForestPanel Colour SW Slat

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative (Green)
      • Colour Selection Woodstain

    • ForestPanel Iroko Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish

    • ForestPanel Iroko Slat (Horizontal Pattern)

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish

    • ForestPanel FR

      • Sustainably Sourced European Redwood PAR Slat
      • Holz Prof Fire Retardant Coating (Clear Finish)

  • Locking System

    • Eurocylinder Lock (Sliding Doors Only)

      • Locating Pin
      • Eurocylinder Key-Operated Deadlock
      • 100% Stainless Steel Mechanism
      • Integral handle with sliding door frame
