Bike Stores

urbanspec M-Series Bike stores

urbanspec M-Series Bike Stores are the versatile, in-line cycle storage system with efficient footprint utilisation and door access to the front of each store. There are three model depths and two model widths with extensive configurations available for frame colour, panel type, access control and integral green roof options.

read more...

At 1200mm depth, urbanspec M12 is fitted with vertical cycle racks, urbanspec M15 has a 1500mm depth and stores cycles on semi-vertical racks, while the 1800mm depth model, the urbanspec M18, is fitted with Sheffield type cycle stands. urbanspec MT is designed to accommodate the two-tier rack system. All variants can be specified with up to six connected modules, each with its own access door. This design reduces the required footprint by enclosing only the cycle rack space.

urbanspec M-Series Bike Stores are manufactured in the UK with an all-steel modular frame designed to accommodate cladding panel types in colour coated steel and timber. Frame components are finished in hot dip galvanised with colour powder coated options available. Height adjustable base plates enable effective ground fixing.

Access control options are specified from the modular lock design enabling key operated, mechanical keypad, electronic fob and smartphone activated systems to be selected. For high-security applications, urbanspec M-Series Bike Stores with Secured by Design specifications achieve Sold Secure SS104 – Gold Specification for Mechanical Security Systems for Pedal Cycles.

urbanspec M-Series Bike Store variations are available for download below as CAD blocks and BIM models with NBS specifications.

show less
Quote My Project
NBS button

urbanpec M-Series Bike stores Model Variants

  • M-Series Bike Stores

    urbanspec M-Series Bike Stores

    Offering versatility from a linear layout, urbanspec M-Series Bike Stores are designed as connected units with models that enable bikes to be stored in a vertical, semi-vertical or level position, providing efficient footprint utilisation for new developments.
    View product specifications
  •  M-Series 2-Tier Rack Bike Stores

    urbanspec M-Series 2-Tier Rack Bike Stores

    Designed to accommodate the two-tier bike racking system, MT-Series Bike Stores are a compact design that optimises footprint by enclosing the cycle rack space only. All units can be configured for detailed specifications.
    View product specifications

urbanspec M-Series Bike Stores Specification & Options

  • Product Availability and Dimensions


    urbanspec M-Series bike stores are available in three different depths, to accommodate the storage of cycles using ‘sheffield’ type stands (M18), semi-vertical cycle racks (M15), wall-mount racks (M12) or two-tier cycle racks (MT). Unit doors can be specified as either left hand or right hand hinged depending on the access route. (Please note all dimensions listed below are maximum external dimensions).
    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    M12.12 2no. Cycles (V)128012902060DownloadDownloadDownload
    M12.245no. Cycles (V)128024902060DownloadDownloadDownload
    M12.368no. Cycles (V)128036902060DownloadDownloadDownload
    M12.4811no. Cycles (V)128048902060DownloadDownloadDownload
    M12.6015no. Cycles (V)128060902060DownloadDownloadDownload
    M12.7218no. Cycles (V)128072902060DownloadDownloadDownload
    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    M15.12 2no. Cycles (SV)158012902060DownloadDownloadDownload
    M15.246no. Cycles (SV)158024902060DownloadDownloadDownload
    M15.369no. Cycles (SV)158036902060DownloadDownloadDownload
    M15.4813no. Cycles (SV)158048902060DownloadDownloadDownload
    M15.60 16no. Cycles (SV)158060902060DownloadDownloadDownload
    M15.7220no. Cycles (SV)158072802060DownloadDownloadDownload
    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    M18.122no. Cycles188012802060DownloadDownloadDownload
    M18.246no. Cycles188024902060DownloadDownloadDownload
    M18.368no. Cycles188036902060DownloadDownloadDownload
    M18.4812no. Cycles188048902060DownloadDownloadDownload
    M18.6014no. Cycles188060902060DownloadDownloadDownload
    M18.7218no. Cycles188072902060DownloadDownloadDownload
    ModelStorageDepth
    [mm]
    Width
    [mm]
    Height
    [mm]
    Data SheetCAD ModelTech Drawing
    MT1212no. Cycles333027102890DownloadDownloadDownload
    MT2424no. Cycles333051102890DownloadDownloadDownload
    MT3636no. Cycles333075102890DownloadDownloadDownload
    MT4848no. Cycles333099102890DownloadDownloadDownload
  • Cladding & Finishes

    The modular frame series creates external wall panels in coloured steel, timber slat and coated mesh. Bespoke designs can be accommodated. Images are for illustrative purposes only.
    • Firenze Freestyle Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection 30% Gloss Finish
      • Laser Cut Hole Pattern Design
    • Firenze Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection
    • Firenze Anthracite Grey

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Nordic Night Black

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Leaf Green

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • Firenze Walnut Brown

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish
    • ForestPanel SW Slat

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative (Green)
    • ForestPanel SW TGV

      • Sustainably Sourced European Redwood TGV Plank
      • Pressure Treated Preservative (Green)
    • ForestPanel Cedar Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish
    • ForestPanel Iroko Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish
    • ZedPanel V-Mesh Black

      • 4mm Vertical Wire / 5mm Horizontal Wire / 200mm x 50mm Aperture Size
      • Colour Powder Coated Wire Black
    • ZedPanel V-Mesh Green

      • 4mm Vertical Wire / 5mm Horizontal Wire / 200mm x 50mm Aperture Size
      • Colour Powder Coated Wire Green
  • Locking Systems

    App-based, electronic fob, mechanical keypad, key operated systems and integral slide bolt for individual padlock user access.
    • Latch + Eurocylinder Lock

      • Self-Latching Daybolt
      • Eurocylinder Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles
    • Slide Bolt + Padlock

      • Self-Latching Daybolt
      • Integral Slide Bolt / Handle with Padlock Provision
    • Latch + RFID Lock

      • Self-Latching Daybolt
      • RFID-operated Eurocylinder Lock Release
      • User Control via app or web portal
    • Latch + Code Secure Lock

      • Code Secured Entrance
      • Battery operated up to 150,000 open/close cycles
      • LED-Illuminated code keypad / IP66 rated Aluminium housing
  • Cycle Rack Options

    urbanspec cycle stores are designed for compatibility with the extensive urbanspec range of cycle hoops and racks.
    • urbanspec WM Wall Mounted Cycle Racks

    • urbanspec ST Cycle Stands

    • urbanspec SV Semi-Vertical Cycle Racks

    • urbanspec T2 Two-Tier Racks
