Asymmetric Bike Shelters

CST 20 ( 3no Shelters)
urbanspec CST 20 (3no Shelters), Asymmetric Bike Shelters – HD Galvanised Finish (Shelter / Stands) – Two-Tier Bike Racks
CST 20 ( 3no Shelters)
CS10 (2 Bay)
CS10 (2 Bay) Single-Row Asymmetric Cycle Shelter

urbanspec CS Asymmetric bike shelters

urbanspec CS Single Row Asymmetric Bike Shelters successfully combine weather protection with architectural value, with an asymmetric radius roof form and clear span centrally supported structure.

read more...

urbanspec CS can be used as either a standalone shelter or as a series of shelters forming a cycle compound with central ‘flying roof’ panels added for additional weather protection between shelters. UV protected polycarbonate roof panels with aluminium glazing system combine clean aesthetics with a long service life. The all-steel framework has a hot dip galvanised finish as standard with customisation options including colour powder coated frames and racks, custom laser cut logo to end frames and LED lighting.

urbanspec CS provides a 2700mm cover width for a single row of bikes with standard ‘sheffield’ type stands while the CST model accommodates two-tier cycle racks and custom dimensions can be accommodated as a special build. The radius steel support structure has a central base plate design that can be specified for either surface fix or subsurface ground fixings.

CS Shelter models are available for download as CAD blocks or 2D technical drawings with NBS Specification References.

show less
quote my project

urbanspec Single row asymmetric bike shelter model variants

  • CS Single Row Bike Shelters

    CS Single Row Asymmetric Roof Bike Shelters

    urbanspec CS Bike Shelters successfully combine weather protection with architectural value, with an asymmetric radius roof form and clear span centrally supported structure providing cover for a single row of bike racks. Single unit or multiple bay series installations can be specified.
    View product specifications

  • CST Single Row Two-Tier Rack Asymmetric Bike Shelters

    urbanspec CST Bike Shelters optimise effective optimisation of available footprint, providing weather protection for a single row of two-tier bike racks with architectural style. Configurations for capacity are available including series installations with ‘add on’ bays.
    View product specifications

urbanspec CS Product Specification & Options

  • Product Specifications

    CENTAUR CS is manufactured in 4100mm and 5100mm module widths for 10 and 12 cycle capacities. Custom dimensions are available to special order.
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    CS1010no. Cycles270341802363DownloadDownloadDownload
    CS1212no. Cycles270351802363DownloadDownloadDownload
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    CST1818no. Cycles272041802791DownloadDownloadDownload
    CST2222no. Cycles269251802815DownloadDownloadDownload

  • Cycle Stand Options

    CENTAUR ST cycle stands are supplied for each CL cycle shelter. These can be either toastrack sets mounted on steel rails for surface fixing or as root fixed stands.

    • Rail Fix (Toast Rack)

      Stands are surface mounted to ground fix steel rails.

    • Baseplate

      Integral base plates for individual ground fixing.

    • Root Fix

      Stands are cast into concrete below ground.

    • Two-Tier

      Rack system with integral ground fixing points.

  • Steel Finishes

    urbanspec CS has a hot dip galvanised frame finish as standard and this is a coating that is highly durable in all environments. An optional powder coated finish can be selected from the following RAL colours together with coordinated cycle stands. Images are for illustrative purposes only.

    • Hot – Dip Galvanised

    • Colour Polyester Powdercoat
