urbanspec CLS Double row symmetric bike shelters

The larger version of the CS bike shelter, urbanspec CLS provides weather protection for two rows of bike stands with a 4000mm cover width. With the same architectural design from a symmetric barrel-vaulted roof and centrally supported structure.

read more...

Configurable for layout to optimise bike storage capacity, CLS can be specified as a series unit with add-on bays or combined with CS Shelters to form a bike shelter compound where the site is secure or within an area of high pedestrian traffic and the overall visual impact of the structure is a consideration.

urbanspec CLS provides 4000mm cover width for a double row of bike racks cycles with standard ‘sheffield’ type stands, while the CLST model accommodates two-tier cycle racks for high storage capacity applications. Custom dimensions can be accommodated as a special build. The radius steel support structure has a central base plate design that can be specified for either surface fix or subsurface ground fixings

urbanspec bike shelters are UK manufactured  and the all-steel framework has a hot dip galvanised finish as standard. Customisation options include colour powder coated frames and racks, bespoke laser cut logo to end frames and LED lighting.

UV protected polycarbonate roof panels with aluminium glazing system combine clean aesthetics with a long service life.The radius steel support structure has a central base plate design enabling either surface fix or subsurface ground fixings to be accommodated.

All bike shelter models are available for download as CAD blocks with NBS Specification References.

show less
quote my project

Double row symmetric bike shelter model variants

  • CLS Double Row Symmetric Roof Bike Shelters

    urbanspec CLS is a larger version of the CS, with a symmetrical barrel-vaulted roof form and a central structure protecting a double row of bikes. Customisation options include colour powder coated frames and racks, bespoke laser cut logo to end frames and LED lighting.
    View product specifications

  • CLST Double Row Two-Tier Rack Symmetric Roof Bike Shelters

    urbanspec CLST Bike Shelters optimise effective optimisation of available footprint, providing weather protection for a double row of two-tier bike racks with architectural style. Configurations for capacity are available including series installations with ‘add on’ bays.
    View product specifications

urbanspec CLS Product Specification & Options

  • Product Specifications

    urbanspec CLS is manufactured in 3 standard model types; 5100mm and 6100mm module widths for 20 and 24 cycle capacities and a 6100mm width version increased to 3190mm internal height to accommodate up to 52 cycles with the two-tier cycle rack system. Custom dimensions are available to special order.
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    CLS2020no. Cycles404251503054DownloadDownloadDownload
    CLS24 24no. Cycles404261503054DownloadDownloadDownload
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    CLST4040no. Cycles404251503254DownloadDownloadDownload
    CLST5252no. Cycles404261503254DownloadDownloadDownload

  • Cycle Stand Options

    urbanspec cycle stands and racks are supplied for each bike shelter.

    • Rail Fix (Toast Rack)

      Stands are surface mounted to ground fix steel rails.

    • Baseplate

      Integral base plates for individual ground fixing.

    • Root Fix

      Stands are cast into concrete below ground.

    • Two-Tier

      Rack system with integral ground fixing points.

  • Steel Finishes

    urbanspec CLS has a hot dip galvanised frame finish as standard and this is a coating that is highly durable in all environments. An optional powder coated finish can be selected from the following RAL colours together with coordinated cycle stands. Images are for illustrative  purposes only.

    • Hot – Dip Galvanised

    • Colour Polyester Powdercoat
