Bike-S Modules

Cycle Storage module, Bike S

Price from £3988 excl. VAT

urbanspec Bike-S Modules are a low-profile design with a maximum height of 1485mm for reduced visual impact and the maintenance of clear sightlines. The 2000mm module depth enables positioning within standard car parking bays. Four models are available with storage capacity for 1, 6, 12 or 18 cycles.

Get a quote

Bike-S Product Specifications & Options

  • Product Availability and Dimensions

    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    Bike-S 11no. Cycle220010601490DownloadDownloadDownload
    Bike-S 66no. Cycles220022001490DownloadDownloadDownload
    Bike-S 1212no. Cycles220042201490DownloadDownloadDownload
    Bike-S 18 18no. Cycles220063301490DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    Bike-SF 66no. Cycles220025102150DownloadDownloadDownload
    DownloadDownloadDownload
    Swipe to see more
    ModelStorageDepth
    [mm]    		Width
    [mm]    		Height
    [mm]    		Data SheetCAD ModelTech Drawing
    Bike-SL 44no. Cycles220022001490DownloadDownloadDownload

  • Cladding and Finishes

    Images are for illustrative purposes only.

    • Firenze Freestyle Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection 30% Gloss Finish
      • Laser Cut Hole Pattern Design

    • Firenze Colour Powder Coat

      • Polyester Powder Coated Steel
      • RAL or BS Colour Selection

    • Firenze Anthracite Grey

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Nordic Night Black

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Leaf Green

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • Firenze Walnut Brown

      • Pre-Coated Steel
      • SSAB Greencoat Pural BT Finish

    • ForestPanel SW Slat

      • Sustainably Sourced European Redwood PAR Slat
      • Pressure Treated Preservative (Green)

    • ForestPanel Cedar Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish

    • ForestPanel Iroko Slat

      • Sustainably Sourced Hardwood PAR Slat
      • Untreated Finish

  • Locking System

    App-based, electronic fob, mechanical keypad, key operated systems and integral slide bolt for individual padlock user access.

    • Latch + Eurocylinder Lock

      • Self-Latching Daybolt
      • Eurocylinder Key-operated Self-Latching Bolt Lock
      • 100% Stainless Steel Mechanism / Aluminium Handles

    • Latch + Code Secure Lock

      • Code Secured Entrance
      • Battery operated up to 150,000 open/close cycles
      • LED-Illuminated code keypad / IP66 rated Aluminium housing

    • Latch + RFID Lock

      • Self-Latching Daybolt
      • RFID-operated Eurocylinder Lock Release
      • User Control via app or web portal

    • Slide Bolt + Padlock

      • Self-Latching Daybolt
      • Integral Slide Bolt / Handle with Padlock Provision

  • Design Features

    Vision Panel

    The unique slot pattern vision panels ensure clear lines of sight are maintained through the store for personal security.

    Integral Cycle Racks

    Integral, stepped cycle trays and welded security locking points at the front of the store makes loading and securing cycles easy.

    Optional Door Closer

    Access doors can be fitted with internal closing cylinders to prevent the store being left unsecured.

    Door Lock Protection

    Access doors are locked using a Kitemarked 3-Star Eurocylinder with external anti-drill plate welded to door frames.

    Green Roof Options

    Optional lightweight sedum or wildflower green roof with integrated liner, reservoir and growing medium.
